Dean’s been back in touch with his take on a Denver and Rio Grande Western model railroad:

“Al, Cheers from Dean in New Mexico.

I’m working on a new L-shaped N-scale railroad.

The plans are below, but first I want to talk a little bit about its history. This layout will be located in northern New Mexico (actually well know to me since I live there).

Before I get to the history of my new fictitious Santa Fe Northern Railroad, I want to talk about the history of the Denver and Rio Grand Western Railroad in New Mexico. See the map below.

The D&RGW came down from Alamosa to Antonito (both in Colorado) as shown in the yellow line. This part of the railroad was converted to standard gauge early on and is still an active railroad running a few trains a month.

At Antonito the line continued onto Chama, New Mexico, on what is now the Cumbres and Toltek tourist line. Also leaving Antonito was the narrow gauge Chili Line down to Santa Fe, New Mexico.

The line traveled south on the plateau following closely what is now Highway 285. If you drive on this road, you can see much of the grading still visible, and at the town of Tres Piedras there is still an original water tower.

At a place above the ghost town, Embudo, the line dropped over a steep grade down to the Rio Grande river. At Embudo you can still see a turntable pit and another water tower. The line then followed the river, through Española. It crossed the Rio at a place named Otowi crossing, then proceeded to Santa Fe.

The original plan was to follow the river all the way down to the border with Mexico, but the Santa Fe RR won that race. Unfortunately, the Chili Line was abandoned in 1942 and the rails were pulled up to support the war effort.

The history of Otowi was written up in the book The House at Otowi Bridge: The Story of Edith Warner and Los Alamos , which talks about how Oppenheimer and other scientists at Los Alamos during the war often dropped in on Edith. She was the station master at Otowi and also ran a lunch stop.

In my imaginary history of the area, the Chili Line and the Los Alamos Lab did not exist. Instead, the Santa Fe Northern was built, following the route of the Chili Line, from Santa Fe down to Otowi, but then it turned away from the river into the mountains to service a large coal mine at Redondo and to haul off lumber from the forest.

A large coal mine actually existed in northern New Mexico in Madrid, a town south of Santa Fe. It serviced the Santa Fe Railroad until diesels replaced the coal locos. But coal does not exist in the area of the Santa Fe Northern, since that area is the remains of a large extinct volcano which blanketed the area with lava and volcanic ash. But my railroad, my history!

Below is my layout plans as developed using SCARM (free version can be downloaded from scarm.info). It is a double ovel connected by two sets of crossovers. The railroad can be run in three main modes.

1) Work train from Santa Fe to mine. Train runs CCW from Santa Fe to Otowi Crossing on the yellow or lower loop, continuing on taking the blue loop up to the mine.

2) One train over the whole main line. Start anywhere with both switch crossings set to the straight position, and eventually the train will get back to the original spot.

3) Two trains going in opposite directions, one on the yellow line, one on the blue. This requires both trains to utilize the red track, necessitating focused attention from the operator to manage the switches effectively. This would be a good thing to show kids.

The three modes of operation are all demonstrated using the Model Train Simulator add-on to SCARM in my YouTube.

Below is the 3D version of the plan showing track elevations at key points. The lowest point is at Otowi with an elevation of 0”. Tracks rise up to Santa Fe and the yards at 1”, then continue up to the mine at 2”. By breaking this up into three main elevations, the track inclines are decreased by half—this brilliant change was suggested by a viewer of my YouTube channel.

I had hoped to have this layout well under construction by now with the baseboard built and some of the track laid. But unfortunately, ” life is what happens when you’re making other plans”. A five-day stay at a hospital with a slow recovery has slowed me down. Hopefully, I can report progress in a month or so.

Thanks Al, for everything you do.

Dean”

A big thanks to Dean for sharing his Denver and Rio Grande Western model railroad plans – you all know how much I like a layout with a theme so I’m looking forward to seeing this one.

Now on to Kerry:

“Hello Alastair: I’ve watched many of the contributions of others. I have an HO layout 5’ x 9’ I started 30 years ago, but didn’t really make alot of progress until the last 8 years. Converted to DCC last year. Modeling the early 50’s. I used Atlas track and turnouts as that’s all I could afford 25 years ago. They still work, even with DCC technology.

Kerry”

I do love it when I receive stuff about 30 or 50 year old locos or track working just fine. Just makes me smile.

That’s all for this time folks.

Please do keep ’em coming.

And if today is the day you get started on your layout, the Beginner’s Guide is here.

Best

Al

PS More HO scale train layouts here if that’s your thing.

Dan’s been in touch with another missive, which includes a HO scale coal fired power plant:

(You can see the first part here: Northern Pacific railway.)

“Here is the second part of the Inland Pacific Railway We used car cards and switch lists to do the work at the businesses and industries. The finished layout was fully and correctly signaled. We had hand held phones at all yards. We had a time table with the rules of operation and signal indication information.

My part was the scenery design and about 75% of the buildings. He did the electrical and DCC work, track work, and construction.

The first set of photos are a review of the general “floor” plan and track plan as well as the dispatcher desk.

The foot print of all three layers.

The track plan.

The dispatch panel frame I made for the panels.

The finished dispatch panel. Terry (owner of the layout) did all of the hard work. The panel worked just like the prototype.

Close up look. The rows of lights on the left and right are the indicators for the lower storage tracks as well as the run through tracks. The lights on the right side are easier to see.

Simplified schematic.

Cover of the book. It was a multi page booklet.

Signal aspects as it pertained to the layout.

Random photos of the top level. There was as interchange with the B&O RR. Mostly coal for the power plant. To the left you see hopper cars going left. There was mirror strategically placed to make it look as if it went beyond the wall.

If you have ever had to attach a second level you know the issues involved. This photo shows the power plant segment. It had a loop around the power plant. It had a 6 foot section to attach to the wall because we had 30 inch radius track. Terry constructed what amounted to as a spooked wheel with a flat side to the wall.

The power plant. Notice the three stacks. The middle one had a length of all thread from under the building running up through it and up thru the I-beam that supported the floor if the house above. This supported the weight of entire wheel assembly. There was a minimum amount of attachments to the wall.

The coal unload facility for the power plant. I made the pile using a thick mailing tube and cut holes for the coal to fall out. The pile is just cone that I covered with white glue and sprinkled on the coal.. In this case real coal.

Photo 15 A box board plant. Basically card board for packaging. Goods go out to plants that make the boxes.

Photo 16 A large grain elevator. The Walther’s kit plus extensions. Unit trains came in and out of here. The yard in front was for all of the top level locals and switching except the for the coal at the power plant . I usually did this job and it took about 3 hours to do.

This is also a VIEW BLOCK. The upper level trains come from the left after passing through the wall and passing behind (actually through) the elevator. In the next photos I will show more.

Here is a better view of the set up. The building on the left is a tomato condiment plant. The grey building to the left of the elevator is the office. Between them is a slight “peek-a-boo” where you can see the view blocked trains pass.

A better view of the mini scene I did as the “Peek-a-boo” to verify that the trains was indeed there. The dispatcher knew. It was just fun to watch.

The plain grey building at the far right is a freezer storage place. Back in the days before folks had home freezers the rented space to store large amounts of frozen food. I needed a building to hide the hidden track that had not entered the “stage” yet.

After leaving the storage building the hidden track passed under the city scene and behind the rock wall.

The upper level passes through the helix. This is to the left of the elevator and some more industries. There were at least 12 industries to be switched on the upper level.

Photo 23 Just a scene along the way on the upper level.

Photo 22 The “connecting” of the previous photo. The train goes past several industries and at the far end it swings left past the Carnation dry milk plant and back past the B&O interchange. What you don’t see behind the interchange is more hidden track. At the very far end where you can just see a signal crossing is the, now viable track, about to pass behind the Carnation plant to the other side of the layout where the grain elevator awaits.

Photo 25 Local approaching another switching job.

Photo 26 A wider view.

Photo 29 Here is where the upper level hidden track reappears. Out of a tunnel and under a bridge helping to hide the sudden appearance of the trains. The track will continue to eventually the large elevators.

Below is a feed processing plant and to it’s right the track goes to the lower level storage and run through track.

This was a great layout to operate. There was the hump job, dispatcher, the locals, and run through trains to keep things interesting during the operations.

SantaFedan”

A big thanks to Dan for sharing his ho scale coal fired power plant pics.

You can see more of Dan in the Hall of Fame.

That’s all for this time folks.

Please do keep ’em coming.

And if today is the day you get started on your layout, the Beginner’s Guide is here.

Best

Al

PS More HO scale train layouts here if that’s your thing.

Need buildings for your layout? Have a look at the Silly Discount bundle.

The talented Boyd has been back in touch – this time he’s added a model railroad lumber town, complete with a Jurassic Park, which I absolutey loved.

It’s the theme and the personal touches that make a layout!

“Hello Al,

It’s hard to believe that another year has passed since my last email. As mentioned before, I pursue outdoor activities and spend several weeks up in Nova Scotia throughout the warmer months, and only work on the layout over the Winter.

As usual, I did not get as much done as I planned, but did commit to getting a good start on the next section.

If you recall, there will eventually be a section dedicated to each of the grandkids, and this year’s goal was to get in the basics of Jaxonville.

The scene begins at the bottom of Mila’s Mountain with a small family operated lumber mill that processes the timber from the logging camp up on the mountain. There is a siding to bring in the logs and take away the packaged lumber products.

As you pass the mill and head into town, you first pass the firehall ( there is currently a funding campaign underway to purchase a new firetruck, but it appears to be off to a slow start ), then there is a section of retail stores, a Tim Horton’s drive through ( I was born and raised in Canada ) then the scene ends with a brewery, which also has a siding to bring in raw material and take away the brew.

Above Jaxonville is a Jurassic Theme Park to reflect one of Jaxon’s main interests.

Each of the stores has interior lighting, and there are streetlights along the main street. The wiring was a new learning experience, and took some time, but I think the end result was worth the effort.

There are still many details to fill in, more people, vehicles, etc., as well as a playground and park to finish out the foreground. That won’t happen until next fall, so I thought I would send in progress to date.

I will also send a video showing some trains as they pass behind Jaxonville, it is not the greatest of quality and runs a bit long, use as you will.

One other note, my layout originally had a duck under to access the interior space. I knew I would probably tire of that eventually so I had a temporary bridge in there until I decided which direction to go for the final solution.

I stumbled upon a Youtube video of a fellow who designed and built a lift up section using drawer slides, and fashioned a similar unit for my layout, I’ll attach a couple pics of that as well. It is not as professionally finished as his, you can see his video here.

Lumber Mill area

Jaxonville Fire Department

Jaxonville retail area

Brewery

Jurassic Park

Duck under and glide up solution

A continued Thank you for all you do to support the hobby.

Boyd”

A big thanks to Boyd for sharing his model railroad lumber town update.

His layout is one of my faves on the blog. Here are his earlier posts if you want to see it from the very start:

Model train hobby

HO scale logging camp.

HO model train trees.

HO scale scenery

Boyd’s update also reminded me of Paul’s Jurassic Park layout.
